Schroef voor gipsplaat op staal met hoge dichtheid, SQ2 weatherex 4,2x38mm

tap image to zoom

Description

Schroef voor gipsplaat op staal, wheaterex II

Lees meer Lees minder

Applications

Gipsplaat op zwaar staal

Lees meer Lees minder

Norm

Geharmoniseerde norm EN 14566:2008+A1:2009

Request information

Specifications

Identifiers

Artikelnummer: 42TC38MW
GTIN: 8715274045733

Technical specifications

Verbindingstype: Plastic gebonden
Draad materiaal: Carbon met standaard treksterkte
Rotaties per minuut: 2300, 2500, 3000, 3300 RPM

Fastener specifications

Afwerking: Weatherex II
Toepassingsomgeving: Buiten
Kop diameter: 4.2 mm
Punt type: Zelfborend
Punthoek: 110 °
Schroef type kop: Wafer head
Schroef recess: Square 2
Schroefdraad type: Tek
Aantal bevestigingsmiddelen per strip/rol: 50 - 50
Schroeflengte: 38.0 mm
Schroefdiameter: 4.2 mm

CeSpecifications

DOP No: 42TC38MW
Materiaal notificatie op CE label: Niet-gelegeerd staal
Service klasse: 3
Binnendraad diameter: 3.3 mm
Draadlengte: 33.0 mm
Geharmoniseerde norm: EN 14566:2008+A1:2009

Non-technical specifications

Verpakkingshoeveelheid: 1000

Gerelateerde tools

Zie alle producten

Downloads

42TC38MW_nl_CommercialProductSheet_1.5_1757440032175 PDF 1 Mb
42TC38MW_nl_DeclarationOfPerformanceDoP_1.2eu_1757440101265 PDF 59 Kb
